RamanProbe
The original RamanProbe laboratory probe. Efficient focussing and filtering optics are incorporated into a remarkably compact design (4" long x 0.5" diameter), resulting in a versatile sampling tool for the laboratory. The focussed design makes it ideal for analysis through glass and plastic, as well as for measurement of neat solids and surfaces. The patented design (US 5,112,127) completely filters Rayleigh scattering with an attenuation of 108, eliminating background signals from fiber optic cables for optimum data quality over long fiber runs.
| Sampling Head | Stainless-steel, cylindrical, 0.5" diameter (12.7 mm) x 4.25" length (108 mm), with integrated fiber optics |
| Spectral Range | 200 – 3900 cm⁻¹ (Stokes)* |
| Excitation Wavelengths | 488, 514, 532, 632, 670, 785, 830, 976 nm; others available on request |
| Working Distance | 5 mm standard; up to 10 mm optional |
| Fiber Configuration | 105 µm excitation / 200 µm collection fibers, N.A. 0.22, polyurethane jacket. Options: 50–500 µm fiber sizes; stainless-steel jacket; side-viewing model |
| Filter Efficiency | O.D. > 8 at laser wavelength — complete filtering of laser line and quartz contributions |
| Physical Resistance | Resistant to physical shock; operable to 80°C (200°C high-temp option available) |
| Cable Length | 5 m standard; up to 200 m optional |
| Safety Features | Emission indicator (standard); Class I sample holders available |
| Coupling System | FC (standard) or SMA 905 connectors |
APPLICATIONS
RPB Low-Cost RamanProbe
A breakthrough for routine laboratory Raman spectroscopy. A modified design based upon the patented RamanProbe optical layout has resulted in drastic cost-reduction with limited performance tradeoff. Available for three excitation wavelengths, the RPB can be coupled to a variety of spectrograph designs. Optical filtering of 106 offers efficient attenuation of the Rayleigh line for background-free spectra. The probe is lightweight and compact, featuring a manual safety shutter with built-in calibration standard.
| Sampling Head | Anodized aluminum probe, 4.2" x 1.5" x 0.5" (107 x 38 x 12.7 mm), with 1.5" stainless-steel probe tip |
| Spectral Range | 250 – 3900 cm⁻¹ (Stokes)* |
| Excitation Wavelengths | 514, 532, 632, 670, 785 (782–788), 830 nm |
| Working Distance | 7.5 mm standard; 5 or 10 mm optional |
| Fiber Configuration | 105 µm excitation / 200 µm collection fibers, N.A. 0.22, polyurethane jacket |
| Filter Efficiency | O.D. > 6 at laser wavelength |
| Physical Resistance | Operable to 80°C |
| Cable Length | 1.5 m standard |
| Safety Features | Manual safety shutter (U.S. Patent 6,621,574); Class I sample holders available |
| Coupling System | FC (standard) or SMA 905 connectors |
APPLICATIONS
Immersion RamanProbe
The RamanProbe II is a versatile fiber optic probe for immersion analysis based on the patented optics of the original RamanProbe. The 8" long body and removable sleeve enable the probe to be immersed directly in solutions for true in situ analysis. The focal distance is selectable to optimize measurement of dark or turbid solutions. The standard immersion sleeve is stainless-steel with a sapphire window. The sleeve can be quickly removed for routine measurement of neat solids or samples in bottles.
| Sampling Head | Stainless-steel cylindrical probe with removable immersion sleeve, 5/8" (15.8 mm) diameter x 8" (230 mm) length |
| Spectral Range | 250 – 3900 cm⁻¹ (Stokes)* |
| Excitation Wavelengths | 514, 532, 632, 670, 785, 830 nm; others available on request |
| Working Distance | Sliding immersion sleeve provides selectable working distance for clear and turbid solutions |
| Fiber Configuration | 100 µm excitation / 200 µm collection fibers, N.A. 0.22, stainless-steel cabled fiber. Options: 50–400 µm fiber sizes |
| Filter Efficiency | O.D. > 8 at laser line — complete filtering of laser line and quartz contributions |
| Physical Resistance | Entire probe head operable to 200°C. Sapphire window sealed with PTFE gasket. Quartz window available (recommended for 633 and 670 nm) |
| Cable Length | 5 m standard; up to 200 m optional |
| Safety Features | Emission indicator (standard); Class I sample holders available |
| Coupling System | FC (standard) or SMA connectors |
APPLICATIONS
Reaction RamanProbe
A versatile, probe for reactions at moderately elevated temperatures and pressures. The compact design places the optical head at the tip of the 5/8" diameter probe for maximum throughput. The standard model is 13" long, constructed from 316 stainless-steel with an o-ring seal around the sapphire window. Various elastomeric materials can be used to withstand many chemical environments. For optimum resistance, Hastelloy C construction with a gold gasket is available. Also available with a compression-welded sapphire window for an increased pressure rating. Flanges can be welded to the probe for mounting into process lines and vessels.
| Sampling Head | Stainless-steel cylindrical probe tip, 5/8" (15.9 mm) diameter x 13" (330 mm) length |
| Spectral Range | 200 – 3900 cm⁻¹ (Stokes)* |
| Excitation Wavelengths | 514, 532, 632, 670, 785, 830 nm; others available on request |
| Working Distance | User-adjustable between 5 and <1 mm to optimize measurement of clear and opaque solutions |
| Fiber Configuration | 100 µm excitation / 200 µm collection fibers, N.A. 0.22, stainless-steel jacket. Options: 50–500 µm fiber sizes |
| Filter Efficiency | O.D. > 8 at laser line — complete filtering of laser line and quartz contributions |
| Physical Resistance | Rated to 1500 psi and 200°C |
| Chemical Resistance | SS sleeve, sapphire window, Kalrez o-ring. Hastelloy C with gold gasket available for corrosive environments |
| Cable Length | 5 m steel-jacketed (standard); up to 100 m on request. PVC coating optional |
| Safety Features | Emission indicator (standard) |
| Coupling System | FC (standard) or SMA connectors |
APPLICATIONS
Process RamanProbe
The Process RamanProbe combines the best features of optical design and mechanical robustness for sensitive process monitoring. Based upon the same quality optics as the standard RamanProbe, the probe body is kept at a distance from the reactor with an extension tube that interfaces directly into reactors and process lines. With the optional purgeable housing, the probe is suitable for most industrial environments. The probe uses only hard oxide filters that withstand high temperature and humidity. The pressure-tight stainless-steel extension tube is equipped with a compression-welded sapphire window at the tip. Now available in Hastelloy C as well as 316 stainless steel.
| Sampling Head | 13/16" (206 mm) diameter probe body with stainless-steel extension tube, 3/8" (9.5 mm) diameter x 9" (228 mm) length |
| Spectral Range | 200 – 3900 cm⁻¹ (Stokes)* |
| Excitation Wavelengths | 514, 532, 632, 670, 785, 830 nm; others available on request |
| Working Distance | User-selectable fixed working distance, 0.5 to 6 mm. User-adjustable versions available |
| Fiber Configuration | 100 µm excitation / 200 µm collection fibers, N.A. 0.22, stainless-steel jacket. Options: 50–500 µm fiber sizes |
| Filter Efficiency | O.D. > 8 at laser line — complete filtering of laser line and quartz contributions |
| Physical Resistance | Rated to 3000 psi and 500°C. External optics must be maintained below 200°C (purgeable housing sold separately) |
| Chemical Resistance | 316 SS sleeve, sapphire window (flat or lensed), gold seal — resistant to corrosive environments. Hastelloy C available |
| Cable Length | 5 m steel-jacketed (standard); up to 200 m on request. PVC coating optional |
| Safety Features | Emission indicator and safety shutter (standard, U.S. Patent 6,621,574) |
| Coupling System | FC (standard) or SMA connectors |
APPLICATIONS
Fiber Optic Cable Lengths
Custom fiber optic cables in a range of lengths to connect your RamanProbe to any Raman system. All cables are optimized for Raman excitation and collection wavelengths.
| Available Lengths | 1.5 m to 200 m; custom lengths on request |
| Standard Connectors | SMA 905 or FC |
| Fiber Type | Low-OH fiber for 785 nm; high-OH fiber for UV excitation |
| Jacketing | Polyurethane standard; stainless-steel jacket and PVC overcoat available |
| Custom Options | Alternative connector types; armored jacketing; custom lengths |
Probe Accessories
A full range of accessories to mount, position, and optimize your InPhotonics Raman probes for any sampling geometry or environment.
| Sample Holders | Class I sample holders for liquids and solids; vial and cuvette holders |
| Probe Mounts | Adjustable probe mounts and positioning hardware |
| Fiber Adapters | SMA and FC fiber optic adapters |
| Flow Cells | Flow cells for liquid samples; custom cell configurations available |
| Custom Options | Right-angle probe heads; extension rods; OEM configurations |
